LEXIUM MHDA1004 - Power Wiring

51
Power Wiring
AC Mains Power
Supply
Connection
The following diagram shows the connections for the AC mains power supply input
to the 17D drive.
*3 x 230 V +10% max. with a BPH055 Servo motor
Bias Supply
Connection
The following diagram shows the connections for the bias power supply input to the
17D drive.
(1) The current must not exceed 10A through these pin.
Continued on next page
Lexium 17D
1
2
3
4
FN1
FN2
FN3
L1
L2
L3
L1
L2
L3
PE
PE
XO
Three phase
60Hz
208... 480 Vac*
A
208...230V
60Hz
208...230V
60Hz
208...480V
60Hz
230...480V
50Hz
Three phase
50Hz
230... 480 Vac*
Lexium 17D
1
+24 Vdc
X4
2
3
+
4
-
+24 Vdc
Com +24 Vdc
Com +24 Vdc
+24 V
33V
( 1 )
(
1 )
External 24 Vdc
supply (SELV)
FUS
L1
L2
PE
