Mounting and Physical
Dimensions
At a Glance
What’s in this
Chapter
This chapter provides information on the mounting requirements for, and physical
dimensions of, the Lexium 17D series servo drives and includes the following
topics:
Topic Page
Installation safety precautions 34
Installation considerations 36
Drive mounting and physical dimensions 37
External Regen resistor mounting and dimensions 39
Choke mounting and dimensions 41
