LEXIUM MHDA1004 - Page 199

C
B
A
890 USE 120 00 185
A
AC mains power supply connection, 51
acronyms and abbreviations, 12
additional safety guidelines, 9
air flow, 36
analog
I/O connection, 70
input mode 0 servo loop, 162
input specifications, 123
output specifications, 123
automatic card recognition, 30
auxiliary encoder interface, 67
B
B885-11x
control wiring, 144
encoder wiring, 145, 146
wiring to drive, 144
bias
input specifications, 113
power, 27
supply, connection, 51
BPH055 Motor Power Connector (Drive
end) Diagram, 155
brake output specifications, 122
breakout module wiring
for Premium CAY, 138, 139
C
cable
separation, 36
shield connections, 49
cables
drive to motor, 130
parts list, 130
CAN bus cable, 76
CANopen Interface, 75
connection diagram for LEXIUM 17D, 47
connection to different mains supply
networks, 17
connector and LED location, 169
control wiring
B885-11x, 144
MOT 201, 140
Quantum 140 MSx, 143
controlling pre-programmed motion tasks,
172
current controller servo loop, 160
D
DC Link capacitor recharging, 28
default settings, 30
determining external regen resistor size,
177
digital control, 23
digital inputs and outputs, 72
dimensions, physical, 46, 50, 51, 53, 54,
56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66,
68, 70, 71, 72, 136, 169, 174
Index
