Gocator Snapshot Sensors: User Manual
Gocator Web Interface • 160
See Adding and Configuring a Measurement Tool on page 134 for instructions on how to add
measurement tools.
The tool may be unable to fit a circle to the profile when attempting the fit on a small number of
relatively collinear data points.
Measurements, Features, and Settings
Measurement Illustration
Radius
Measures the radius of the circle.
X
Finds the circle center position in the X axis.
Z
Finds the circle center position in the Z axis.
Measurements
Type Description
Center Point
The center point of the fitted circle.
Features
For more information on geometric features, see Geometric Features on page 141.
