Gocator Snapshot Sensors: User Manual
Gocator Device Files • 382
Element Type Description
0 – Time (µs)
1 – Encoder (mm)
Measurement 32u Selected measurement source.
Measurement.options 32u (CSV) List of available measurement sources.
The delay specifies the time or position at which the analog output activates. Upon activation, there
is an additional delay before the analog output settles at the correct value.
Serial
The Serial element defines settings for Serial output.
Element Type Description
Protocol 32s
Serial protocol:
0 – ASCII
1 – Selcom
Protocol.options 32s (CSV) List of available protocols.
Selcom Section
See Selcom below.
Ascii Section
See Ascii on the next page.
Measurements 32u (CSV) Selected measurement sources.
Measurements.options 32u (CSV) List of available measurement sources.
Serial Child Elements
Selcom
Element Type Description
Rate 32u Output bit rate.
Rate.options 32u (CSV) List of available rates.
Format 32s
Output format:
0 – 12-bit
1 – 12-bit with search
2 – 14-bit
3 – 14-bit with search
Format.options 32s (CSV) List of available formats.
DataScaleMin 64f Measurement value corresponding to minimum word value.
DataScaleMax 64f Measurement value corresponding to maximum word value.
Delay 64u Output delay in µs.
Selcom Child Elements
