Gocator Snapshot Sensors: User Manual
Gocator Device Files • 342
Element Type Description
DecisionMax 64f Maximum decision threshold.
Percent
(Percentile measurement only)
64f Error percentile.
ProfilePanel
A ProfilePanelelement defines settings for a profile panel tool and one or more of its measurements.
Element Type Description
Name String Tool name.
Features
Collection Not used.
Source 32s Profile source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions on page 326 elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
RefSide 32s Setting for reference side to use.
MaxGapWidth 64f Setting for maximum gap width (mm).
LeftEdge
ProfilePanelEdge
Element for left edge configuration.
RightEdge
ProfilePanelEdge
Element for right edge configuration.
Measurements\Gap
Gap/Flush
measurement
Gap measurement.
Measurements\Flush Gap/Flush
measurement
Flush measurement.
Measurements\LeftGapX Gap/Flush
measurement
Left Gap X measurement.
Measurements\LeftGapZ Gap/Flush
measurement
Left Gap Z measurement.
Measurements\LeftFlushX Gap/Flush
measurement
Left Flush X measurement.
Measurements\LeftFlushZ Gap/Flush
measurement
Left Flush Z measurement.
ProfilePanel Child Elements
