Gocator Snapshot Sensors: User Manual
Gocator Web Interface • 90
Spacing
The Spacing tab lets you configure the spacing interval.
Spacing Interval
Spacing interval is the spacing between data points in resampled data. A larger interval creates scans with
lower X/Y resolution, reduces CPU usage, and potentially increases the maximum frame rate. A larger
interval also reduces the data output rate. For more information on resampled data, see Resampling on
page 42.
To configure the spacing interval:
1. Go to the Scan page.
2. Choose Surface mode in the Scan Mode panel.
If this mode is not selected, you will not be able to configure the spacing interval.
3. Expand the Sensor panel by clicking on the panel header or the button.
4. Click the button corresponding to the sensor you want to configure.
The button is labeled Top, Bottom, Top-Left, or Top-Right, depending on the system.
Spacing is configured separately for each sensor.
5. Click the Spacing tab.
6. Do one of the following:
7. Select a spacing interval level.
8. Save the job in the Toolbar by clicking the Save button .
Advanced
The Advanced tab contains settings to configure camera gain and material characteristics.
