Gocator Snapshot Sensors: User Manual
Gocator Web Interface • 91
To configure advanced settings:
1. Go to the Scan page.
2. Switch to Video mode.
Using Video mode while configuring the settings lets you evaluate their impact.
3. Expand the Sensor panel by clicking on the panel header or the button.
4. Click on the Advanced tab.
5. Configure material characteristics and camera gain.
For more information, see Material below and Camera Gain on the next page.
6. Save the job in the Toolbar by clicking the Save button .
7. Check that scan data is satisfactory.
Material
Data acquisition can be configured to suit different types of target materials. For many targets, changing
the setting is not necessary, but it can make a great difference with others.
You can select preset material types in the Materials setting under the Advanced tab. The Diffuse
material option is suitable for most materials. The Interreflective material option is useful with targets
whose surface may show reflections from other surfaces in the scanned area, for example inside a
countersunk hole or on surfaces with concave features.
