Gocator Snapshot Sensors: User Manual
Gocator Device Files • 312
Element Type Description
X 64f X start(mm).
Y 64f Y start (mm).
Z 64f Z start (mm).
Width 64f X extent (mm).
Length 64f Y extent (mm).
Height 64f Z extent (mm).
ZAngle 64f Z Angle start (degrees).
ZAngle.used Bool Whether or not this property is used.
Region3D Child Elements
Element Type Description
X 32u X start (pixels).
Y 32u Y start (pixels).
Width 32u X extent (pixels).
Height 32u Y extent (pixels).
Window Child Elements
Element Type Description
Grid
Grid
Layout grid information.
MultiplexingBank 32u Multiplexing bank ID
MultiplexingBank.used 32u Whether or not this field can be specified
MultiplexingBank.value 32u Actual value used by system
Layout Child Elements
Element Type Description
@used Bool Whether or not this section is used.
Row 32s Device row position in grid layout.
Row.value 32s Value in use by the sensor, useful for determining value when used is
false.
Column 32s Device column position in grid layout.
Column.value 32s Value in use by the sensor, useful for determining value when used is
false.
Direction 32s Sensor orientation direction.
Direction.value 32s Value in use by the sensor, useful for determining value when used is
false.
Grid Child Elements
Tracking
Tracking is only available on Gocator 2300 and 2400 series sensors.
