Gocator Device Files • 345
Element Type Description
Stream\Id 32u The stream source ID.
Feature
ProfileFeature
Element for feature detection.
Measurements\X Position tool
measurement
X measurement.
Measurements\Z Position tool
measurement
Z measurement.
Features\Point GeometricF
FeatureTypes.htm
eature
Point PointFeature
Element Type Description
id (attribute) 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Position Tool Measurement
ProfileRoundCorner
A ProfileRoundCorner element defines settings for a profile round corner tool and one or more of its
measurements.
