Gocator Snapshot Sensors: User Manual
Gocator Device Files • 346
Element Type Description
Name String Tool name.
Features
Collection Not used.
Source 32s Profile source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions on page 326 elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
RefDirection 32s
Setting for reference side to use:
0 – Left
1 – Right
Edge
ProfilePanelEdge
Element for edge configuration
Measurements\X Round Corner tool
measurement
X measurement.
Measurements\Z Round Corner tool
measurement
Z measurement.
Measurements\Angle Round Corner tool
measurement
Angle measurement.
ProfileRoundCorner Child Elements
Element Type Description
EdgeType 32s
Edge type:
0 – Tangent
1 – Corner
MinDepth 64f Minimum depth.
MaxVoidWidth 64f Maximum void width.
SurfaceWidth 64f Surface width.
SurfaceOffset 64f Surface offset.
NominalRadius 64f Nominal radius.
EdgeAngle 64f Edge angle.
RegionEnabled Bool Whether or not to use the region. If the region is disabled,
ProfilePanelEdge
