Gocator Snapshot Sensors: User Manual
Gocator Device Files • 365
Element Type Description
Measurements\Z Opening tool
measurement
Z measurement.
Measurements\Width Opening tool
measurement
Width measurement.
Measurements\Length Opening tool
measurement
Length measurement.
Measurements\Angle Opening tool
measurement
Angle measurement.
Features\CenterPoint
GeometricFeature
CenterPoint PointFeature
Element Type Description
id (attribute) 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Opening Tool Measurement
SurfacePlane
A SurfacePlane element defines settings for a surface plane tool and one or more of its measurements.
Element Type Description
Name String Tool name.
SurfacePlane Child Elements
