Gocator Snapshot Sensors: User Manual
Gocator Device Files • 364
Element Type Description
0 – Rounded
1 – Slot
NominalWidth 64f Nominal width (mm).
NominalLength 64f Nominal length (mm).
NominalAngle 64f Nominal angle (degrees).
NominalRadius 64f Nominal radius (mm).
WidthTolerance 64f Radius tolerance (mm).
LengthTolerance 64f Length tolerance (mm).
AngleTolerance 64f Angle tolerance (degrees).
PartialDetectionEnabled Boolean
Setting to enable/disable partial detection:
0 – Disable
1 – Enable
DepthLimitEnabled Boolean Setting to enable/disable depth limit:
0 – Disable
1 – Enable
DepthLimit
64f
The depth limit relative to the surface. Data below this limit
is ignored.
RegionEnabled Boolean
Setting to enable/disable region:
0 – Disable
1 – Enable
Region
Region3D
Measurement region.
RefRegionsEnabled Boolean
Setting to enable/disable reference regions (Advanced tab):
0 – Disable
1 – Enable
RefRegionCount 32s Count of the reference regions that are to be used.
(
Advanced
tab.)
RefRegions
(Collection) Reference regions. Contains two RefRegion elements of type
SurfaceRegion2D.
AutoTiltEnabled Boolean
Setting to enable/disable tilt correction (Advanced tab):
0 – Disable
1 – Enable
TiltXAngle 64f Setting for custom tilt correction angle X.
TiltYAngle 64f Setting for custom tilt correction angle Y.
Measurements\X Opening tool
measurement
X measurement.
Measurements\Y Opening tool
measurement
Y measurement.
