Gocator Snapshot Sensors: User Manual
Gocator Device Files • 361
Element Type Description
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
SurfaceHole
A SurfaceHoleelement defines settings for a surface hole tool and one or more of its measurements.
Element Type Description
Name String Tool name.
Features
Collection Collection of geometric feature outputs available in the tool.
See SurfaceHole above.
Source 32s Surface source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Y String (CSV) The Y measurements (IDs) used for anchoring.
Anchor\Y.options String (CSV) The Y measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
Anchor\ZAngle String (CSV) The Z Angle measurements (IDs) used for anchoring.
Anchor\ZAngle.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions on page 326 elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
NominalRadius 64f Nominal radius (mm).
RadiusTolerance 64f Radius tolerance (mm).
PartialDetectionEnabled Boolean
Setting to enable/disable partial detection:
0 – Disable
1 – Enable
DepthLimitEnabled Boolean Setting to enable/disable depth limit:
0 – Disable
1 – Enable
SurfaceHole Child Elements
