Gocator Snapshot Sensors: User Manual
Gocator Device Files • 366
Element Type Description
Features
Collection Not used.
Source 32s Surface source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Y String (CSV) The Y measurements (IDs) used for anchoring.
Anchor\Y.options String (CSV) The Y measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
Anchor\ZAngle String (CSV) The Z Angle measurements (IDs) used for anchoring.
Anchor\ZAngle.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions on page 326 elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
RegionsEnabled Boolean
Setting to enable/disable regions:
0 – Disable
1 – Enable
RegionCount 32s Count of the regions.
Regions (Collection) Measurement regions. Contains up to four Region elements
of type Region3D.
Measurements\XAngle Plane tool
measurement
XAngle measurement.
Measurements\YAngle Plane tool
measurement
YAngle measurement.
Measurements\ZOffset Plane tool
measurement
ZOffset measurement.
Measurements\StdDev Plane tool
measurement
Standard deviation measurement
Measurements\MinError Plane tool
measurement
Minimum error measurement
Measurements\MaxError Plane tool
measurement
Maximum error measurement
Measurements\XNormal PlaneMeasurement XNormal measurement
Measurements\YNormal PlaneMeasurement YNormal measurement
