Gocator Snapshot Sensors: User Manual
Gocator Device Files • 341
Element Type Description
measurement
Measurements\Offset Line tool
measurement
Offset measurement.
Measurements\Angle Line tool
measurement
Angle measurement.
Measurements\MinErrorX Line tool
measurement
Minimum Error in Z measurement.
Measurements\MinErrorZ Line tool
measurement
Minimum Error in Z measurement.
Measurements\MaxErrorX Line tool
measurement
Maximum Error in X measurement.
Measurements\MaxErrorZ Line tool
measurement
Maximum Error in Z measurement.
Features\Line
GeometricFeature
Line LineFeature.
Features\ErrorMinPoint GeometricFeature ErrorMinPoint PointFeature.
Features\ErrorMaxPoint GeometricFeature ErrorMaxPoint PointFeature.
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
Line Tool Measurement
