Gocator Snapshot Sensors: User Manual
Gocator Web Interface • 166
Measurement Illustration
X
Measures the X position of the bottom of a groove.
Z
Measures the Z position of the bottom of a groove.
Parameter Description
Source The sensor that provides data for the tool's measurements. For more information, see Source on
page 135.
Stream The data that the tool will apply measurements to.
In Surface mode, this setting is only displayed when a section is defined on the surface data.
For more information on sections, see Sections on page 127.
Shape Shape of the groove
Min Depth Minimum depth for a groove to be considered valid.
Min Width Minimum width for a groove to be considered valid. The width is the distance between the
groove corners.
Parameters
