Gocator Snapshot Sensors: User Manual
Gocator Web Interface • 241
Type Description
Center Point
The returned position.
Features
For more information on geometric features, see Geometric Features on page 141.
Parameter Description
Source The sensor that provides data for the tool's measurements.
For more information, see Source on page 135.
Feature The feature the tool uses for its measurements. One of the
following:
l Average
l Median
l Centroid
l Max X
l Min X
l Max Y
l Min Y
l Max Z
l Min Z
To set the region of a feature, adjust it graphically in the
data viewer, or expand the feature using the expand
button ( ) and enter the values in the fields. For more
information on regions, see Regions on page 136.
Filters The filters that are applied to measurement values before
they are output. For more information, see Filters on page
143.
Decision The Max and Min settings define the range that determines
whether the measurement tool sends a pass or fail decision
to the output. For more information, see Decisions on page
142.
Parameters
Anchor Description
X, Y, or Z Lets you choose the X, Y, or Z measurement of another tool
to use as a positional anchor for this tool.
Z angle Lets you choose the Z Angle measurement of another tool to
use as an angle anchor for this tool.
Anchoring
A measurement must be enabled in the other tool for it to be available as an anchor. The anchor
measurement should also be properly configured before using it as an anchor.
For more information on anchoring, see Measurement Anchoring on page 145.
