Gocator Device Files • 354
Element Type Description
Measurements\BevelRadius Countersunk Hole tool
measurement
Bevel Radius measurement.
Measurements\BevelAngle Countersunk Hole tool
measurement
Bevel Angle measurement.
Measurements\XAngle Countersunk Hole tool
measurement
X Angle measurement.
Measurements\YAngle Countersunk Hole tool
measurement
Y Angle measurement.
Measurements\CounterboreDe
pth
Countersunk Hole tool
measurement
CounterboreDepth measurement.
Measurements\AxisTilt CsHoleMeasurement Axis tilt measurement
Measurements\AxisOrientation CsHoleMeasurement Axis orientation measurement.
Features\CenterPoint
GeometricFeature
CenterPoint PointFeature
Element Type Description
id (attribute) 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Features
Collection Collection of geometric feature outputs available in the
tool. See SurfaceCsHole on page 352.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Countersunk Hole Tool Measurement
