Gocator Snapshot Sensors: User Manual
Gocator Device Files • 370
Element Type Description
TipHeight 64f Height of stud’s tip.
RegionEnabled Boolean Setting to enable/disable region.
Region
Region3D
Measurement region.
RefRegionsEnabled Boolean
Setting to enable/disable reference regions:
0 – Disable
1 – Enable
RefRegionCount 32s Count of the reference regions that are to be used.
(
Advanced
tab.)
RefRegions (Collection) Reference regions. Contains up to four RefRegion elements
of type SurfaceRegion2D. (Advanced tab.)
AutoTiltEnabled Boolean
Setting to enable/disable tilt correction (Advanced tab):
0 – Auto Set
1 – Custom
TiltXAngle 64f Setting for custom tilt correction angle X.
TiltYAngle 64f Setting for custom tilt correction angle Y.
Measurements\BaseX Stud tool
measurement
BaseX measurement.
Measurements\BaseY Stud tool
measurement
BaseY measurement.
Measurements\BaseZ Stud tool
measurement
BaseZ measurement.
Measurements\TipX Stud tool
measurement
TipX measurement.
Measurements\TipY Stud tool
measurement
TipY measurement.
Measurements\TipZ Stud tool
measurement
TipZ measurement.
Measurements\Radius Stud tool
measurement
Radius measurement.
Features\TipPoint GeometricFeature TipPoint PointFeature
Features\BasePoint GeometricFeature BasePoint PointFeature
Element Type Description
id (attribute) 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
Stud Tool Measurement
