Gocator Snapshot Sensors: User Manual
Gocator Web Interface • 99
The following settings can be tuned to improve the accuracy and reliability of part detection.
Setting Description
Height Threshold
Determines the height threshold for part detection. The setting for Threshold Direction
determines if parts should be detected above or below the threshold. Above is typically
used to prevent the belt surface from being detected as a part when scanning objects on
a conveyor.
Threshold Direction Determines if parts should be detected above or below the height threshold.
Gap Width Determines the minimum separation between objects on the X axis. If parts are closer
than the gap interval, they will be merged into a single part.
Gap Length
Determines the minimum separation between objects on the Y axis. If parts are closer
than the gap interval, they will be merged into a single part.
Padding Width Determines the amount of extra data on the X axis from the surface surrounding the
detectedpart that will be included. This is mostly useful when processing part data with
third-party software such as HexSight, Halcon, etc.
Padding Length Determines the amount of extra data on the Y axis from the surface surrounding the
detectedpart that will be included. This is mostly useful when processing part data with
third-party software such as HexSight, Halcon, etc.
Min Area Determines the minimum area for a detected part. Set this value to a reasonable
minimum in order to filter out small objects or noise.
Max Part Length Determines the maximum length of the part object. When the object exceeds the
