LSIS S100 User Manual

184
Table of Functions
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
91 0h155B
Pulse input
amount
display
Pulse Monitor
(kHz)
0.00-50.00(kHz)
0.00 O O I/P p.76
92 0h155C
TI input filter
time constant
TI Filter 0-9999(ms) 10 O O I/P p.76
93 0h155D
TI Minimum
input pulse
TI Pls x1 0.00-32.00(kHz) 0 O O I/P p.76
94 0h153E
TI output at
Minimum
pulse (%)
TI Perc y1 0.00-100.00(%) 0.00 O O I/P p.76
95 0h155F
TI Maximum
input pulse
TI Pls x2 0.00-32.00(kHz) 32.00 O O I/P p.76
96 0h1560
TI Output at
Maximum
pulse (%)
TI Perc y2 0-100(%) 100.00 O O I/P p.76
97 0h1561
TI rotation
direction
change
TI Inverting
0
No
0:No O O I/P p.76
1 Yes
98 0h1562
TI
quantization
level
TI Quantizing
0.00
39
, 0.04-
10.00(%)
0.04 O O I/P p.76
99 0h1563
SW1(NPN/PNP
),
SW2(V2[I2])
Status display
IO SW State
Bit
00~11
00 O O I/P -
00
V2, NPN
01
V2, PNP
10
I2, NPN
11
I2, PNP
