Table of Functions
183
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property*
V/F SL Ref.
14
3-Wire
-
15
2nd Source
p.111
16
Exchange
-
17
Up
-
18
Down
-
20
U/D Clear
-
21
Analog Hold
p.78
22
I-Term Clear
-
23
PID Openloop
-
24
P Gain2
-
25
XCEL Stop
p.96
26
2nd Motor
-
34
Pre Excite
-
38
Timer In
-
40
dis Aux Ref
-
46
FWD JOG
-
47
REV JOG
-
49
XCEL-H
p.91
50
User Seq
p.115
51
Fire Mode
p.123
52
KEB-1 Select
-
84 0h1554
Multi-function
input terminal
On filter
selection
Dl Delay Sel
P7 ~ P1
1 1111
O O I/P p.112
0
Disable(Off)
1 Enable(On)
85 0h1555
Multi-function
input terminal
On filter
DI On Delay 0-10000(ms)
10 O O I/P p.112
86 0h1556
Multi-function
input terminal
Off filter
DI Off Delay 0-10000(ms)
3 O O I/P p.112
87 0h1557
Multi-function
input
contact
selection
DI NC/NO Sel
P7 P1
000
0000
X O I/P p.112
0
A contact
(NO)
1
B contact (NC)
89 0h1559
Multi-step
command
delay time
InCheck Time 1-5000(ms)
1 X O I/P p.79
90 0h155A
Multi-function
input terminal
status
DI Status
P7 P1
000
0000
O O I/P p.112
0
release(Off)
1
Connection
(On)
