LSIS S100 User Manual

182
Table of Functions
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
53
41
0h1535
I2 minimum
input current
I2 Curr x1 0.00-20.00(mA) 4.00 O O I/P p.74
54
41
0h1536
I2 output at
Minimum
current (%)
I2 Perc y1 0.00-100.00(%) 0.00 O O I/P p.74
55
41
0h1537
I2 maximum
input current
I2 Curr x2 0.00-24.00(mA) 20.00 O O I/P p.74
56
41
0h1538
I2 output at
Maximum
current (%)
I2 Perc y2 0.00-100.00(%) 100.00 O O I/P p.74
61
41
0h153D
Changing
rotation
direction of I2
I2 Inverting
0
No
0:No O O I/P p.74
1 Yes
62
41
0h153E
I2
quantization
level
I2 Quantizing
0.00
39
,0.04-
10.00(%)
0.04 O O I/P p.74
65 0h1541
P1 terminal
function
setting
P1 Define
0 None
1:Fx X O I/P p.81
1 Fx
66 0h1542
P2 terminal
function
setting
P2 Define 2 Rx 2:Rx X O I/P p.81
67 0h1543
P3 terminal
function
setting
P3 Define 3 RST 5:BX X O I/P -
68 0h1544
P4 terminal
function
setting
P4 Define 4 External Trip 3:RST X O I/P -
69 0h1545
P5 terminal
function
setting
P5 Define 5 BX 7:Sp-L X O I/P -
70 0h1546
P6 terminal
function
setting
P6 Define 6 JOG 8:Sp-M X O I/P -
71 0h1547
P7 terminal
function
setting
P7 Define 7 Speed-L 9:Sp-H X O I/P p.79
8
Speed-M
p.79
9
Speed-H
p.79
11
XCEL-L
p.91
12
XCEL-M
p.91
13
RUN Enable
-
