LSIS S100 User Manual

Table of Functions
199
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
26 0h1B1A
Underload
warning time
UL Warn
Time
0.0-600.0(s) 10.0 O O I/P -
27 0h1B1B
Underload fault
selection
UL Trip Sel
0 None
0:None O O
I/P - 1 Free-Run
2 Dec
28 0h1B1C
Underload fault
time
UL Trip Time 0.0-600.0(s) 30.0 O O I/P -
29 0h1B1D
Underload
lower limit level
UL LF Level 10-30(%) 30 O O I/P -
30 0h1B1E
Underload
upper limit level
UL BF Level 30-100(%) 30 O O
I/P -
31 0h1B1F
No motor
motion at
detection
No Motor
Trip
0 None
0:None O O I -
1 Free-Run
32 0h1B20
No motor
detection
current level
No Motor
Level
1-100(%) 5 O O I -
33 0h1B21
No motor
detection delay
No Motor
Time
0.1-10.0(s) 3.0 O O I -
40 0h1B28
Electronic
thermal fault
selection
ETH Trip Sel
0 None
0:None O O I/P -
1 Free-Run
2 Dec
41 0h1B29
Motor cooling
fan type
Motor
Cooling
0 Self-cool
0:Self-
cool
O O I/P -
1 Forced-cool
42 0h1B2A
Electronic
thermal 1
minute rating
ETH 1min 120-200(%) 150 O O I/P -
43 0h1B2B
Electronic
thermal
continuous
rating
ETH Cont 50-150(%) 120 O O I/P -
45 0h1B2D BX trip mode BX Mode
0
Free-Run
0 X O I/P
-
1 Dec
50 0h1B32
Stall prevention
motion and flux
braking
Stall Prevent
bit 0000-1111
0000 X O X -
00
01
Accelerating
