Installing the Inverter

Items

Check Point

Ref.

Result

Are the control terminal screws tightened to their specified

torques?

p.16

Is the total cable length of all control wiring < 165ft (100m)?

p.27

Is the total length of safety wiring < 100ft (30m)?

p.27

Miscellaneous

Are optional cards connected correctly?

Is there any debris left inside the inverter?

p.16

Are any cables contacting adjacent terminals, creating a

potential short circuit risk?

Are the control terminal connections separated from the

power terminal connections?

If capacitors have been in use for more than two years, have

they been replaced?

Has a fuse been installed for the power source?

p.253

Are the connections to the motor separated from other

connections?

If the fans have been in operation for more than three years,

have they been replaced?

p. 245

Note

STP (Shielded Twisted Pair) cable has a highly conductive, shielded screen around twisted cable pairs.

STP cables protect conductors from electromagnetic interference.
