LSIS S100 User Manual

41
Learning to Perform Basic Operations
No. Name Display Description
J Jog frequency command
R Int 485 frequency command
1 ~9, A~F Multi-step frequency command
3
Multi-
functional key
settings
JOG Key Keypad JOG operation mode
Local/Remote Able to select either local or remote operation
UserGrpSelKey
Register or delete user group parameters in parameter
mode
4
Inverter
operation
status
STP Motor stopped
FWD Operating in forward direction
REV Operating in reverse direction
DC DC output
WAN Warning
STL Stall
SPS Speed Search
OSS S/W overcurrent protective function is on
OSH H/W overcurrent protective function is on
TUN Auto Tuning
