Learning to Perform Basic Operations
Table of Display Modes
The following table lists the 5 display modes used to control the inverter functions.
Monitor mode MON
Displays the inverter’s operation status information. In this
mode, information including the inverter’s frequency
reference, operation frequency, output current, and voltage
Parameter mode PAR
Used to configure the functions required to operate the
inverter. These functions are divided into 14 groups based on
Trip mode TRP
Used to monitor the inverter’s fault trip information,
including the previous fault trip history.
When a fault trip occurs during inverter operation, the
operation frequency, output current, and output voltage of
the inverter at the time of the fault may be monitored.
This mode is not displayed if the inverter is not at fault and
fault trip history does not exist.
Config mode CNF
Used to configure the inverter features that are not directly
related to the operation of the inverter. The settings you can
configure in the Config mode include keypad display
language options, monitor mode environment settings,
communication module display settings, and parameter
duplication and initialization.
