Learning to Perform Basic Operations
Parameter Setting Mode
The following table lists the functions groups under Parameter mode.
Function Group Name
Keypad Display
Description
Drive DRV
Configures basic operation parameters. These include
ACC/Dec time settings, operation command settings, and
functions necessary for operation.
Basic BAS
Configures basic operation parameters. These parameters
include motor parameters and multi-step frequency
parameters.
Advanced ADV
Configures acceleration or deceleration patterns,
frequency limits, energy saving features, and,
regeneration prevention features.
Control CON
Configures the features related to speed search and KEB
(kinetic energy buffering).
Input Terminal IN
Configures input terminal–related features, including
digital multi–functional inputs and analog inputs.
Output Terminal OUT
Configures output terminal–related features, including
digital multi–functional outputs and analog outputs.
Communication COM
Configures the communication features for the RS-485,
Modbus-RTU and Metasys N2. Optional communication
module related features may be configured as well, if one
is installed.
Application APP
Configures functionsrelated to auto sequence operation
and PID control.
Protection
PRT
Configures motor and inverter protection features.
Motor 2 (Secondary
motor)
M2 Configures the secondary motor-related features.
User Sequence
USS
Used to implement simple sequences with various
function blocks.
User Sequence
Function
USF
