LSIS S100 User Manual

64
Learning Basic Features
Basic Tasks
Description
Ref.
Motor rotation control
Configures the inverter to limit a motor’s rotation direction.
p.86
Automatic start-up at
power-on
Configures the inverter to start operating at power-on. With
this configuration, the inverter begins to run and the motor
accelerates as soon as power is supplied to the inverter. To use
automatic start-up configuration, the operation command
terminals at the terminal block must be turned on.
p.87
Automatic restart after reset
of a fault trip condition
Configures the inverter to start operating when the inverter is
reset following a fault trip. In this configuration, the inverter
starts to run and the motor accelerates as soon as the inverter
is reset following a fault trip condition.
For automatic start-up configuration to work, the operation
command terminals at the terminal block must be turned on.
p.88
Acc/Dec time configuration
based on the Max.
Frequency
Configures the acceleration and deceleration times for a motor
based on a defined maximum frequency.
p.89
Acc/Dec time configuration
based on the frequency
reference
Configures acceleration and deceleration times for a motor
based on a defined frequency reference.
p.90
Multi-stage Acc/Dec time
configuration using the
multi-function terminal
Configures multi-stage acceleration and deceleration times for
a motor based on defined parameters for the multi-function
terminals.
p.91
Acc/Dec time transition
speed (frequency)
configuration
Enables modification of acceleration and deceleration
gradients without configuring the multi-functional terminals.
p.93
Acc/Dec pattern
configuration
Enables modification of the acceleration and deceleration
gradient patterns. Basic patterns to choose from include linear
and S-curve patterns.
p.94
Acc/Dec stop command
Stops the current acceleration or deceleration and controls
motor operation at a constant speed. Multi-function terminals
must be configured for this command .
p.96
Linear V/F pattern operation
Configures the inverter to run a motor at a constant torque. To
maintain the required torque, the operating frequency may
vary during operation.
p.97
Square reduction V/F
pattern operation
Configures the inverter to run the motor at a square reduction
V/F pattern. Fans and pumps are appropriate loads for square
reduction V/F operation.
p.98
User V/F pattern
configuration
Enables the user to configure a V/F pattern to match the
characteristics of a motor. This configuration is for special-
purpose motor applications to achieve optimal performance.
p.99
Manual torque boost
Manual configuration of the inverter to produce a momentary
torque boost. This configuration is for loads that require a large
amount of starting torque, such as elevators or lifts.
p.101
Automatic torque boost
Automatic configuration of the inverter that provides “auto
tuning” that produces a momentary torque boost. This
p.101
