F07-16 CommLoss Tout Sets the time-out value for communication
loss detection.
0.0-30.0 sec 0
F07-17 EN Speed Scale Sets the scaling factor for the EtherNet/IP
speed setting/monitor
-15–15 0
F07-18 EN Current Scale Sets the scaling factor for the EtherNet/IP
output current setting/monitor
-15–15 0
F07-19 EN Torque Scale Sets the scaling factor for the EtherNet/IP
torque setting/monitor
-15–15 0
F07-20 EN Power Scale Sets the scaling factor for the EtherNet/IP
power monitor
-15–15 0
F07-21 EN Voltage Scale Sets the scaling factor for the EtherNet/IP
voltage setting/monitor
-15–15 0
F07-22 EN Time Scale Sets the scaling factor for the EtherNet/IP
time setting/monitor
-15–15 0
F07-23 to
F07-32
DOA116 (1 to 10) Dynamic parameters that contain the Modbus
addresses used for programmable registers in
the output assembly 116. Data residing in
bites 20 to 39 of assembly 116 will be written
to the respective Modbus registers identified
by the addresses contained in these
parameters. No data is written to the Modbus
registers if the parameter setting is 0.
Modbus Address
0x- - - -
0
F07-33 to
F07-42
DOA166 (1 to 10) Dynamic parameters that contain the Modbus
addresses used for programmable registers in
the input assembly 166. Data residing in the
Modbus registers will be written to the
respective assembly 166 bytes 20 to 39. The
Modbus registers are identified by the
addresses contained in these parameters. No
data is written to the programmable registers
if the parameter setting is 0.
Modbus Address
0x- - - -
0
Parameter Display Function Range Default
