•G+ & VG+ Series 4 Technical Manual
November 2020
Page 234
D08-04 Dwell Time @ Stop 0.0 0.0–10.0 sec Page 125
D09-01 SCrv Acc @ Start 0.20* 0.00–10.00 sec Page 126
D09-02 SCrv Acc @ End 0.20* 0.00–10.00 sec Page 126
D09-03 SCrv Dec @ Start 0.20* 0.00–10.00 sec Page 126
D09-04 SCrv Dec @ End 0.20* 0.00–10.00 sec Page 126
D10-01 Heavy/NormalDuty 0 0, 1 - Page 127
D10-02 CarrierFreq Sel 1 1–9, A, F - Page 127
D10-03 CarrierFreq Max 2.0 1.0–15.0 kHz Page 127
D10-04 CarrierFreq Min 2.0 1.0–15.0 kHz Page 127
D10-05 CarrierFreq Gain 0 0–99 - Page 127
D11-01 Hunt Prev Select 1 0, 1 - Page 128
D11-02 Hunt Prev Gain 1.00 0.00–2.50 - Page 128
D11-03 Hunt Prev Time 10 0–500 ms Page 128
D11-05 REV Hunt Pref Gn 0.00 0.00–2.50 - Page 128
E01-01 Input Voltage
230V: 230
460V: 460
575V: 575
230V: 155–255
460V: 310–510
575V: 446–733
VAC Page 129
E01-03 V/f Selection *
V/f: 0–9, A–F, FF
OLV: F, FF
- Page 130
E01-04 Max Frequency 60.0 40.0–150.0 Hz Page 130
E01-05 Max Voltage **
230V: 0.0–255.0
460V: 0.0–510.0
575V: 0.0–733.1
VAC Page 130
E01-06 Base Frequency 60.0 0.0–150.0 Hz Page 130
E01-07 Mid Frequency A
Determined
by E01-03
0.0–150.0 Hz Page 130
E01-08 Mid Voltage A
Determined
by E01-03
230V: 0.0–255.0
460V: 0.0–510.0
575V: 0.0–733.1
VAC Page 130
E01-09 Min Frequency
Determined
by E01-03
0.0–150.0 Page 130
E01-10 Min Voltage
Determined
by E01-03
230V: 0.0–255.0
460V: 0.0–510.0
575V: 0.0–733.1
VAC Page 130
E01-11 Mid Frequency B 0.0 0.0–150.0 Hz Page 131
E01-12 Mid Voltage B 0.0 0.0–733.1 VAC Page 131
E01-13 Base Voltage 0.0 0.0–733.1 VAC Page 131
E02-01 Motor Rated FLA ** ** A Page 135
E02-02 Motor Rated Slip ** 0.00–20.00 Hz Page 135
E02-03*** No-Load Current ** 0–[(E02-01)-1] A Page 135
E02-04 Number of Poles 4 2–48 - Page 135
E02-05*** Term Resistance ** 0.000–65.000 Ω Page 135
E02-06*** Leak Inductance ** 0.0–40.0 % Page 135
E02-07*** Saturation Comp1 0.50 0.00–0.50 - Page 135
E02-08*** Saturation Comp2 0.75 E02-07–0.75 - Page 135
Parameter Parameter Name Default Range Units Reference
