Magnetek IMPULSE G+ 4 Series User Manual

IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 235
E02-09*** Mechanical Loss 0.0 0.0–10.0 % Page 135
E02-10*** Motor Iron Loss ** 0–65535 W Page 135
E02-11 Rated Horsepower ** 0.00–650.00 HP Page 135
E03-02 Stopping Method 1 0, 1 - Page 136
E03-03 Max Frequency 60.0 40.0–150.0 Hz Page 136
E03-04 Max Voltage **
230V: 0.0–255.0
460V: 0.0–510.0
575V: 0.0–733.1
VAC Page 136
E03-05 Base Frequency 60.0 0.0–150.0 Hz Page 136
E03-06 Mid Frequency A
Determined
by E01-03
0.0–150.0 Hz Page 136
E03-07 Mid Voltage A
Determined
by E01-03
230V: 0.0–255.0
460V: 0.0–510.0
575V: 0.0–733.1
VAC Page 136
E03-08 Min Frequency
Determined
by E01-03
0.0–150.0 Hz Page 136
E03-09 Min Voltage
Determined
by E01-03
230V: 0.0–255.0
460V: 0.0–510.0
575V: 0.0–733.1
VAC Page 136
E03-10 Mid Frequency B 0.0 0.0–150.0 Hz Page 136
E03-11 Mid Voltage B 0.0
230V: 0.0–255.0
460V: 0.0–510.0
575V: 0.0–733.1
VAC Page 136
E03-12 Base Voltage 0.0
230V: 0.0–255.0
460V: 0.0–510.0
575V: 0.0–733.1
VAC Page 136
F01-01 PG1 Pulses/Rev 1024 0–60000 PPR Page 137
F01-02 PG1 Rotation Sel 0 0, 1 - Page 137
F01-03 PG1 Output Ratio 1 1–132 - Page 137
F01-04 PG1 #Gear Teeth1 0 0–1000 - Page 137
F01-05 PG1 #Gear Teeth2 0 0–1000 - Page 137
F01-06 PGO-1-H 15 0–100 ms Page 137
F01-11 PG2 Pulses/Rev 1024 0–60000 PPR Page 137
F01-12 PG2 Rotation Sel 0 0, 1 - Page 137
F01-13 PG2 #Gear Teeth1 0 0–1000 - Page 137
F01-14 PG2 #Gear Teeth2 0 0–1000 - Page 137
F01-15 PG2 Output Ratio 1 1–132 - Page 137
F01-16 PGO-2-H 15 0–100 ms Page 137
F01-21 PG Fdbk Loss Sel 1
0–3
NLB: 1
- Page 137
F01-22 PGO-1-S Det Time 2.0 0.0–10.0 sec Page 137
F01-23 PG Overspeed Sel 1
0–3
NLB: 1
- Page 137
F01-24 PG Overspd Level 105 0–120 % Page 137
F01-25 PG Overspd Time 0.0 0.0–2.0 sec Page 138
Parameter Parameter Name Default Range Units Reference
