IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 236
F01-26 PG Deviation Sel 5
Traverse: 0–7
NLB: 5
- Page 138
F01-27 PG Deviate Level 10 0–50 % Page 138
F01-28 PG Deviate Time 0.3 0.0–10.0 sec Page 138
F02-01 AI Function Sel 0 0, 1 - Page 139
F02-02 AI Input Gain 100.0 -999.9–999.9 % Page 139
F02-03 AI Input Bias 0.0 -999.9–999.9 % Page 139
F04-01 AO Ch1 Select 102 1–630 - Page 139
F04-02 AO Ch1 Gain 100.0 -999.9–999.9 % Page 139
F04-03 AO Ch2 Select 103 1–630 - Page 139
F04-04 AO Ch2 Gain 50.0 -999.9–999.9 % Page 139
F04-05 AO Ch1 Bias 0.0 -999.9–999.9 % Page 139
F04-06 AO Ch2 Bias 0.0 -999.9–999.9 % Page 139
F04-07 AO Opt Level Ch1 0 0, 1 - Page 139
F04-08 AO Opt Level Ch2 0 0, 1 - Page 139
F05-01 DO Ch1 Select F 0–148 - Page 141
F05-02 DO Ch2 Select F 0–148 - Page 141
F05-03 DO Ch3 Select F 0–148 - Page 141
F05-04 DO Ch4 Select F 0–148 - Page 141
F05-05 DO Ch5 Select F 0–148 - Page 141
F05-06 DO Ch6 Select F 0–148 - Page 141
F05-07 DO Ch7 Select F 0–148 - Page 141
F05-08 DO Ch8 Select F 0–148 - Page 141
F05-09 DO Function Sel 2 0–2 - Page 141
F06-01 Comm Bus Flt Sel 1 0–4 - Page 143
F06-02 EF0 Detection 0 0, 1 - Page 143
F06-03 EF0 Fault Action 1 0–4 - Page 143
F06-04 BUS Err Det Time 2.0 0.0–5.0 sec Page 143
F06-06 Torq Ref/Lmt Sel 0 0, 1 - Page 143
F06-07 Fref PrioritySel 0 0, 1 - Page 143
F06-08 Com Prm Init Sel 0 0, 1 - Page 143
F06-30 PB Node Address 0 0–125 - Page 143
F06-31 PB Clear Select 0 0, 1 - Page 144
F06-32 PB Map Select 0 0, 1 - Page 144
F06-35 CO Node Address 0 0–126 - Page 144
F06-36 CO Baud Rate 6 0–8 - Page 144
F06-50 DN MAC Address 64 0–64 - Page 144
F06-51 DN Baud Rate 4 0–4 - Page 144
F06-52 DN PCA Selection 21 0–225 - Page 144
F06-53 DN PPA Selection 71 0–225 - Page 144
F06-54 DN Idle Flt Det 0 0, 1 - Page 144
F06-55 DN BAUD RATE MEM 0 0–2 - Page 144
Parameter Parameter Name Default Range Units Reference
