MAN B&W MC/MCC, ME/ME-B/MEC/MEGI engines 198 38 662.3
No. Symbol Symbol designation
3.4
Quickopening valve
3.5
Quickclosing valve
3.6
Regulating valve
3.7
Kingston valve
3.8
Ballvalve (cock)
3.9
Buttery valve
3.20 Gate valve
3.2
Doubleseated changeover valve
3.22 Suction valve chest
3.23
Suction valve chest with nonreturn
valves
3.24
Doubleseated changeover valve,
straight
3.25 Doubleseated changeover valve, angle
3.26 Cock, straight through
3.27 Cock, angle
3.28 Cock, threeway, Lport in plug
3.29 Cock, threeway, Tport in plug
3.30 Cock, fourway, straight through in plug
3.3
Cock with bottom connection
3.32
Cock, straight through, with bottom
conn.
3.33 Cock, angle, with bottom connection
3.34
Cock, threeway, with bottom connec-
tion
No. Symbol Symbol designation
4
Control and regulation parts
4.
Handoperated
4.2 Remote control
4.3 Spring
4.4 Mass
4.5 Float
4.6 Piston
4.7 Membrane
4.8 Electric motor
4.9 Electromagnetic
5 Appliances
5.
Mudbox
5.2 Filter or strainer
5.3 Magnetic lter
5.4 Separator
5.5 Steam trap
5.6 Centrifugal pump
5.7 Gear or screw pump
5.8 Hand pump (bucket)
5.9 Ejector
5.0
Various accessories (text to be added)
