MAN B&W Appendix A
Page 3 of 3
MAN Diesel
MAN B&W MC/MCC, ME/ME-B/MEC/MEGI engines 198 38 662.3
Fig. A.01.01: Symbols for piping
The symbols used are in accordance with ISO/R 538967, except symbol No. 2.9
178 30 614.1
No. Symbol Symbol designation
5.
Piston pump
6 Fittings
6.
Funnel
6.2 Bellmounted pipe end
6.3 Air pipe
6.4 Air pipe with net
6.5 Air pipe with cover
6.6 Air pipe with cover and net
6.7 Air pipe with pressure vacuum valve
6.8
Air pipe with pressure vacuum valve with
net
6.9 Deck ttings for sounding or lling pipe
6.0
Short sounding pipe with selfclosing
cock
6.
Stop for sounding rod
No. Symbol Symbol designation
7
Indicating instruments with ordinary
symbol designations
7.
Sight ow indicator
7.2 Observation glass
7.3 Level indicator
7.4 Distance level indicator
7.5 Counter (indicate function)
7.6 Recorder
