10 1. Introduction – Programming Manual
1.
INTRODUCTION
The Wheel balancing & Supervision process control allows continuous monitoring of
the grinding wheel condition with immediate compensation of possible unbalance
during the cycle.
It can be customized to a variety of applications and balancing heads.
1.1.
Interface between Gauge and User
The software uses graphics and/or icons to show the various functions and make
comprehension and use easy and intuitive.
Other conventions used in this program are:
Numbers or text inside a dotted line can be changed.
Icons or text that appear as a phantom image (or grayed out) cannot be selected
on that page or are not available for the application and its options.
1.2.
Programming manual
This guide was written for the gauge system programmer. It will also be useful for
plant personnel who must perform maintenance and for assistance technicians.
In order to make this guide easy to use, several typographical conventions were
chosen:
Folders, sub-folders and page names are in Italics.
Numbers or choices that can be changed are within quotes; i.e. “100 µm".
Front panel keys or software buttons are shown using the current icon.
Names of operator functions are followed by their icon.
