marposs P7WB - Programming Unbalance Limit Values; Programming Wheel Vibration Tolerance Limits

– Programming Manual 13. Programming 81
13.3. Programming unbalance limit values
Page A4 of the “Programming” folder menu map (section 8.2, page 3).
In this stage it is possible to program the wheel vibration tolerance limits (defining
whether the wheel balancing must be considered as optimum, acceptable or
unacceptable).
Select the Programming folder and press .
With **User’s password** active, the password is asked:
• type the password and press .
Press .
Application with 2 channels: press + to select
Channel 1 or Channel 2.
Press function key F1 or to highlight and press
to access the data programming page.
13.3.1. Programming wheel vibration tolerance limits
The value of the wheel vibration tolerance limits can be programmed either as width
(unit of measure "micron" or "inch") or speed (unit of measure "mm/sec" or "inch/sec")
based on the modality defined when configuring the application.
Type of balancing
algorythm (Sec. 13.3.3
page 77)
Programming of
asymmetric filter on
vibration (Sec. 13.3.4
page 78).
Acceleration value limit
(Sec. 13.3.2 page 77).
Wheel vibration limits
(Section 13.3.1 page 75).
