94 14. I/O test – Programming Manual
14.
I/O TEST
The I/O test can be performed in Manual and Automatic mode:
Manual mode: viewing of Inputs status
viewing and/or changing of Outputs status
Automatic mode: viewing of Inputs and Outputs status
Manual operating mode
Select the Inputs and Outputs folder and press
Enter
.
Press to select the icon indicated and
press
Enter
I/O byte test
Section 14.1
I/O bit test
Section 14.2
Field Bus test (Section 14.3)
Pages viewed only in case of
application with Field Bus
Automatic operating mode
Select the Inputs and Outputs folder and press
Enter
.
I/O bit test
Section 14.2
