70 11. Measurement adjustment – Programming Manual
1
Maximum value of channel 1 signal
2
Minimum value of channel 1 signal
3
F4 key for resetting channel 1 minimum and maximum values
The indications are similar for channel 2.
Note: Stop display (F3 key ): at the display start (F3 key ) it is asked
whether the minimum and maximum values must be reset. Select the
desired option in the dialog box and press .
11.6.5.
Gap&Crash graphical thresholds
Display and change of the Gap and Crash threshold values relevant to the displayed
channel(s).
Note: **User’s Password** active: the threshold values can be changed only if
the password was typed when entering the page.
1
3
2
Channel 2 values
1
2
3
4
