– Programming Manual 22. Application examples 141
Balancing of two wheels on the same axis
Channel 1
INT RPM #1
1
Channel 2
INT RPM #2 (or 1)
2
The balancing cycle is simultaneously performed on the two wheels by programming
a dedicated balancing algorithm. This because with the only rotation axis, the mutual
influence of the vibrations generated by the unbalance present on the two wheels is
inevitable.
Balancing head 1
(RPM INT #1)
Accelerometer 2
(
)
Wheel #1 Wheel #2
Balancer card
“Two channels simultaneously”
Accelerometer 1
(
)
Balancing head 2
(RPM INT #2)
Channel 1 Channel 2
