Parameter Address
Default Min Max Unit Logic Diagram
Binary counts
COUNT: Function group COUNT
217 047
0: Without
[spacer]
Cancelling function group COUNT or including it in the configuration. If the
function group is cancelled from the configuration, then all associated settings
and signals are hidden, with the exception of this setting.
7.1.3 Function Parameters
7.1.3.1 Global
Parameter Address
Default Min Max Unit Logic Diagram
PC link
PC: Command blocking
003 182
0: No Fig. 3-5, (p. 3-9)
[spacer]
When command blocking is activated, commands are rejected at the PC
interface.
[spacer]
PC: Sig./meas.val.block.
003 086
0: No Fig. 3-5, (p. 3-9)
[spacer]
When signal and measured value blocking is activated, no signals or measured
data are transmitted through the PC interface.
Parameter Address
Default Min Max Unit Logic Diagram
“Logical”
communication
interface 1
COMM1: Command block. USER
003 172
1: Yes Fig. 3-6, (p. 3-11)
[spacer]
When command blocking is activated, commands are rejected at communication
interface 1.
[spacer]
COMM1: Sig./meas.block.USER
003 076
0: No Fig. 3-7, (p. 3-12)
Fig. 3-8, (p. 3-13)
Fig. 3-9, (p. 3-14)
[spacer]
When signal and measured value blocking user is activated, no signals or
measured data are transmitted through communication interface COMM1.
