MAIN: Conn.meas.circ. IP,d
010 170
1: Standard Fig. 3-40, (p. 3-65)
[spacer]
The vectorial sum of the phase currents of end a to d is governed by the
connection of the measuring circuits. If the connection is as shown in Chapter
“Installation and Connection”, then the setting must be Standard. If the
connection direction is reversed then the setting must be Opposite. Instead of
accounting for connection reversal applied to one end in the settings
for DIFF: Vec.gr. ends a-b PSx, DIFF: Vec.gr. ends a-c PSx,
DIFF: Vec.gr. ends a-d PSx, it is possible to account for it in the settings
for connection of the measuring circuits.
[spacer]
MAIN: Conn.meas.circ. IY,a
010 141
1: Standard Fig. 3-40, (p. 3-65)
[spacer]
MAIN: Conn.meas.circ. IY,b
010 151
1: Standard Fig. 3-40, (p. 3-65)
[spacer]
MAIN: Conn.meas.circ. IY,c
010 161
1: Standard Fig. 3-40, (p. 3-65)
[spacer]
If the connection is as shown in Chapter “Installation and Connection”, then the
setting must be Standard. If the connection direction is reversed then the
setting must be Opposite.
[spacer]
MAIN: Meas. value rel. IP
011 030
0.00 0.00 0.20 Inom Fig. 3-46, (p. 3-78)
Fig. 3-49, (p. 3-80)
[spacer]
Setting for the minimum current that must be exceeded so that measured
operating values of the phase currents and, if applicable, derived currents are
displayed.
[spacer]
MAIN: Meas.value rel. Ineg
011 048
0.000 0.000 0.200 Inom
[spacer]
MAIN: Meas.value rel. Ipos
011 058
0.000 0.000 0.200 Inom
[spacer]
Setting for a minimum current that must be exceeded in order for the P634 to
display the negative-sequence (positive-sequence) current as measured
operating data.
[spacer]
MAIN: Meas. value rel. IN
011 031
0.000 0.000 0.200 Inom Fig. 3-47, (p. 3-79)
Fig. 3-48, (p. 3-79)
Fig. 3-49, (p. 3-80)
[spacer]
Setting for the minimum current that must be exceeded so that the measured
operating value of the residual current is displayed.
