Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
MAIN: Meas. value rel. IY
011 036
0.000 0.000 0.200 IN,nom Fig. 3-47, (p. 3-79)
[spacer]
Setting for the minimum current that must be exceeded in order for the
measured operating value of the current in the neutral-point-to-ground
connection to be displayed.
[spacer]
MAIN: Meas. value rel. V
011 032
0.00 0.00 0.20 Vnom Fig. 3-50, (p. 3-82)
[spacer]
Setting for the minimum voltage that must be exceeded in order for the
measured operating values of the voltage to be displayed.
[spacer]
MAIN: Settl. t. IP,max,del
010 113
15.0 0.1 60.0 min Fig. 3-45, (p. 3-77)
Fig. 3-46, (p. 3-78)
[spacer]
Setting for the time after which the delayed maximum current display shall
reach 95% of the maximum current I
P,max
.
[spacer]
MAIN: Fct.assign. reset 1
005 248
060 000: MAIN: Without function Fig. 3-66, (p. 3-97)
[spacer]
Assigning specific memories and counters which are to be reset jointly if
MAIN: Group reset 1 USER is enabled.
[spacer]
MAIN: Fct.assign. reset 2
005 249
060 000: MAIN: Without function Fig. 3-66, (p. 3-97)
[spacer]
Assigning specific memories and counters which are to be reset jointly if
MAIN: Group reset 2 USER is enabled.
[spacer]
MAIN: Fct.assign. block. 1
021 021
060 000: MAIN: Without function Fig. 3-57, (p. 3-89)
[spacer]
Assignment of functions that will be blocked simultaneously when blocking
input 1 (MAIN: Blocking 1 EXT) is activated.
[spacer]
MAIN: Fct.assign. block. 2
021 022
060 000: MAIN: Without function Fig. 3-57, (p. 3-89)
[spacer]
Assignment of functions that will be blocked simultaneously when blocking
input 2 (MAIN: Blocking 2 EXT) is activated.
[spacer]
MAIN: Fct.assign. block. 3
021 048
060 000: MAIN: Without function Fig. 3-57, (p. 3-89)
[spacer]
Assignment of functions to be blocked together if blocking input 3
(MAIN: Blocking 3 EXT) is activated.
[spacer]
MAIN: Fct.assign. block. 4
021 049
060 000: MAIN: Without function Fig. 3-57, (p. 3-89)
[spacer]
Assignment of functions to be blocked together if blocking input 4
(MAIN: Blocking 4 EXT) is activated.
