22.2 PROPERLY WORKING CHECK
Functionality to check Procedure
Portal probes - Power on the Minisentry-
2. The screen should display
« Searching » followed by « Probe found », « Initializing » &
« Configuring » and final state « Ready »
Detection of the Frisker CSP
probes
-
Connect a Frisker CSP probe. The screen should display
« Searching » followed by « Probe found », « Initializing »,
« Configuring » and final state measuring screen
Powered by the sector
- Check that the charging LED lights green after the power
connection.
Internal battery
- Check that symbol is present on the top banner of the
LCD screen.
Powered by 12VDC power supply - Disconnect sector and connect 12VDC power supply
- Check that the charge LED lights green orange or red when
connecting 12VDC.
USB stick detection
- Open the menu, and go to « USB mode », then « Connect
USB stick ». (see § 12.3)
- Check the communication with the USB stick.
Detection on PC - Open the menu, and go to « USB mode », then « Connect to
a PC » (see § Erreur ! Source du renvoi introuvable.).
- Check that the MiniSentry-2 is accessible from the PC..
Loud speaker sound - Adjust the volume to check the operation of the speaker (see §
9.10.2).
Navigation buttons
- Browse the menu using at least once the 5 buttons to check
their operation.
Backlight - Adjust the level of backlight to check the correct operation (see
§ 9.10.1).
Contrast - Adjust the level of contrast to check the correct operation (see
§ Erreur ! Source du renvoi introuvable.).
Sensor and optional light tower - Perform an « Enter wait
» measure to check the correct
operation of sensors (see § 9.6) and red / green light tower.
Digital I/O check - Check the state of the relays with an ohmmeter (see § Erreur !
Source du renvoi introuvable.).
Receipt of data by the RS485 - Connect the Minisentry-2 to a PC via the I/O RS485 connector.
-
Open a software using the ModBus protocol and then
interrogate the device.
