18.2 NETWORKING
Communication with the Minisentry-2 can be done via an RS485 network following the ModBus
protocol.
18.3 MODBUS SETTING
To change the slave ID of the device:
1. Connect the device to a PC and launch the « Connect to a PC » USB mode .
2. From the file Explorer open the « /MINISENTRY2/config/deviceSettings.cfg » file with a text
editor. In the section [globalSettings] replace the value of the "modbusSlaveId" field by
desired ID.
Required serial port configuration:
− Speed: 115200 bauds
− Data bits: 8
− Parity : None
− Stop bit: 1
− Flow control: None
18.3.1 ModBus data
The modbus data isn’t yet available in the current release, but it will come in the a future software
version.
