USER MANUAL

MINISENTRY-2

107911_D User manual MINISENTRY-2_En.docx

MIRION TECHNOLOGIES (Canberra)S.A.S., BP249, ZI de Vauzelles, 37602

Loches Cedex

135 / 170

29.4 MAIN POWER SUPPLY CONNECTOR KIT

Item Designation Qty Order No.

2 Connector – cables – protection – Fuses

1 108335

3 Screws
