USER MANUAL
MINISENTRY-2
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra)S.A.S., BP249, ZI de Vauzelles, 37602
25 ASSEMBLY GUIDE, PEDESTRIAN CONFIGURATION
25.1 PART LIST
Item Description
1 Footplate for each post with flat washers and wing nuts
2 Primary detector post with MiniSentry 2 Monitor
3 Top cross piece with attached elbows for pedestrian configuration
4 Secondary detector post
5 End caps (x2) for vehicle configuration needs and shipping
6 Power cord
- Kit for Extended passage width (91.5 cm (36 in)) (Option)
