USE MANUAL

MINISENTRY-2

136 / 170

107911_D User manual MINISENTRY-2_En.docx

MIRION TECHNOLOGIES (Canberra) S.A.S, BP249, ZI de Vauzelles, 3760

Loches Cedex

29.5 SWITCH ON/OFF KIT

Item Designation Qty Order No.

2 Switch and cable 1 108336
