USER MANUAL
MINISENTRY-2
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra)S.A.S., BP249, ZI de Vauzelles, 37602
To show or hide Frisker probe measure, press the key.
9.9 MEASURE SETTINGS
: « Measure settings » are only accessible at the « Administrator » and « Technician » user
level (To change the user level, refer to § 9.12).
9.9.1 Unit
Unit of MiniSentry-2 can be set and is applied for all measure modes of the portal probe.
The Frisker probe unit can be set separately (see § 9.9.5).
Units of portal probes available are:
For unit systems
set (§ 9.9.6)
Possible Unit Values
SI c/s, Bq and Ci
US cpm, dpm and Ci
For Portal probe of MiniSentry-2:
1. Press the key to access the main menu.
Note: The « Measure Mode » line is selected by default. If necessary, press the or keys to
select the line « Measure settings ».
